Recommended Configurations |
Poles Height | 3-40M |
Shape | Round conical, Octagonal tapered, Straight square, Tubular stepped, etc.
Shafts made of steel sheet that folded into required shape and welded longitudinally by automatic welding machine |
Material | Q235/Q345,Iron, Steel, Aluminum |
Brackets/ Arm | Single or double brackets/ arm are in the shape and dimension as per customers requirement |
Welding | It has past flaw testing; Internal and external double welding makes the welding beautiful in shape. And conforms with international welding standard of CWB5.EN 15614 |
Thickness | 1.8mm-30.0mm |
Surface Treatment | Hot dip galvanization with thickness of 80-100mm average in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123, IS 2626:1985,BS EN ISO 1461 |
Base plate mounted | Base plate is square or round in shape with slotted holes for anchor bolt and dimension as per customers requirement. |
Wind resistance | Customized according to customer's environment |
Powder coating | Pure polyester powder painting color is optional according to RAL Color standard. |
Power | Red: ≤ 5W | Green: ≤ 5W |
Operating Voltage | 100-240VAC 50/60Hz | 12V or 24V DC |
LED Q'ty | Red: 96 pcs | Green: 96 pcs |
Apply Diameter | Ф200 mm (Ф8 inches) |
Operating Temp. | -40~+75 ºC |
Wavelength | Red: 625±5nm | Green: 500±5nm |
Operating Humidity | 10% ~ 90% |
Visible Range | >500m |
IP Rating | IP54 |
Warranty | 1 Year |
Housing Material | PC or Aluminum |
Customized/Design Service | Offered |
