Product Model Specification Sheet |
Model NO | ZJ-003 |
Parameter | Specification |
Input Power | 45W~270W, 45W per interval |
Color Temperature (CCT) | 2200K/3000K/4000K/5000K/5700K/6500K |
Housing | High-pressure die-cast aluminum (ADC12 aluminum, 500-hour salt spray resistant coating) |
Luminous Efficacy | 100-180Lm/W±5% |
Input Voltage | AC 100-305V |
Frequency Range | 50/60 Hz |
Power Factor | PF≥0.95 |
Color Rendering Index (CRI) | Ra≥70 |
Operating Ambient Temperature | -40℃ to +50℃ |
Operating Ambient Humidity | 20%-90% |
Lamp Lifespan | >100000h |
Protection Level/IP Rating | IP65 |
Mounting Pipe Diameter | φ60mm |
Color Tolerance | 5 SDCM |
Opening Method | Tool-free cavity opening |
Surge Protection | 10kV |
Control (Customized) | 1-10V; Dali; Amplight control interface; CityTouch ex NB-IoT/GPRS |
Installation Height | 3-30m |
Luminous Efficacy | 145LM/W ~ 155LM/W |
Beam Angle | 15° /25° /40° /60° /90°/P45° |
Warranty | 3years |
